Usage

The Huntsman Dashboard provides a visual interface for threat hunting, data exploration, and graph analysis. This guide covers the main functional areas of the application.

Dashboard Overview

Access the dashboard at http://localhost:8080/.

The interface is designed as a Single Page Application (SPA) with three primary views:

  • Input View: For ingesting raw text or manually staging artifacts.

  • Monitor View: For tracking the status of running analysis tasks.

  • Results View: For exploring the Intelligence Graph, detection lists, and data lake.

Threat Detection

The Detection module allows you to submit artifacts (IOCs) to various analysis engines using two modes.

1. Auto-Ingestion (Regex)

  1. Navigate to the Auto tab in the Input View.

  2. Paste unstructured logs, CSVs, or text into the Raw Data Ingestion text area.

  3. The system automatically detects and counts artifacts (e.g., IPv4, Domains) using patterns defined in ioc_patterns.yaml.

2. Manual Input

  1. Navigate to the Manual Input tab.

  2. Select an Indicator Type from the dropdown.

  3. Enter the Indicator Value and click Add to stage the artifact.

Executing Analysis

  1. In the Enrichment Modules section, filter and select the desired services (e.g., VirusTotal, Shodan) using the checkboxes.

  2. Click Execute Analysis.

  3. The view will automatically switch to the Monitor View to show task progress.

SuperDB Explorer

SuperDB is the high-performance data lake backing Huntsman. The Explorer interface allows you to run SuperQL queries directly against your collected intelligence. By leveraging a compiled WebAssembly (WASM) version of the SuperDB engine, the frontend performs serverless, client-side ETL operations on loaded data without needing to query the server. For direct queries against the full persistent data lake, please refer to the REST API.

Basic Query Structure

SuperQL uses a pipe-based syntax similar to Splunk or Kusto.

_service = '<value>' | <command> | <command>

Common Examples

  • Filter by IP:

    _service = 'virustotal' | where id == '8.8.8.8'

  • Aggregate Data:

    _service = 'internetdb' | count() by hostnames

  • Text Search:

    _service = 'rss-news' | search 'ransomware'

Visualizing Query Results

Results from SuperDB can be dragged and dropped onto the Graph Canvas to visualize connections between disparate data points.

STIX Visualization

Huntsman natively supports STIX 2.1 (Structured Threat Information Expression) for representing threat intelligence.

Graph Canvas

The central area of the application is a force-directed graph that visualizes STIX objects.

  • Nodes: Represent SDOs (Domain Objects) like Indicators, Malware, or Threat Actors.

  • Edges: Represent SROs (Relationship Objects) like indicates, uses, or attributed-to.

Generating Reports

You can convert any analysis task into a standardized STIX report:

  1. Select a completed task from the History.

  2. Click the “Generate STIX” button in the context menu.

  3. The system will map the raw API data (e.g., from VirusTotal) into valid STIX objects (e.g., ipv4-addr, domain-name).

Icons & Styling

The graph uses standard STIX 2.1 icons to help you quickly identify object types:

  • Malware Icon Malware: Red/Square icons.

  • Identity Icon Identity: Grey/Round icons.

  • Indicator Icon Indicator: Orange/Diamond icons.
